R200 CC
URBAN SUPERBIKE
WITH ICONIC ATTITUDE
IDR 88.000.000*
*OTR JADETABEK
From IDR per month with
per months
IDR 88.000.000*
*OTR JADETABEK
IDR 88.000.000*
*OTR JADETABEK
COLOR VARIANTS
IDR 88.000.000*
*OTR JADETABEK
From IDR per month with
per months
IDR 88.000.000*
*OTR JADETABEK
IDR 88.000.000*
*OTR JADETABEK
COLOR VARIANTS
13.7
KW
Maximum power
15.5
NM
Maximum torque
189
CC
Displacement
9
L
Fuel tank capacity
13.7
KW
Maximum power
15.5
NM
Maximum torque
189
CC
Displacement
9
L
Fuel tank capacity
TECHNICAL SPECIFICATION
1. Width
680 mm
2. Wheelbase
1345 mm
3. Seat Height
770 mm
4. Length
1870 mm
5. Height
1100 mm
6. Fuel Tank
9 liters
1. Width
680 mm
2. Wheelbase
1345 mm
3. Seat Height
770 mm
4. Length
1870 mm
5. Fuel Tank Capacity
9 lt
ENGINE
Mesin
Silinder tunggal, 4 langkah, 4 katup, sistem pelumasan basah paksa, DOHC
Mesin
Silinder tunggal, 4 langkah, 4 katup, sistem pelumasan basah paksa, DOHC
BORE X STROKE
Bore X Stroke
63 x 60.6 mm
Bore X Stroke
63 x 60.6 mm
MAXIMUM POWER
Tenaga Maksimal
13.7 kW @ 8250 rpm
Tenaga Maksimal
13.7 kW @ 8250 rpm
FUEL INJECTION
Injeksi Bahan Bakar
Injeksi elektronik
Injeksi Bahan Bakar
Injeksi elektronik
GEAR & CLUTCH
Gigi & Kopling
Kopling kering sentrifugal otomatis
Gigi & Kopling
Kopling kering sentrifugal otomatis
FRONT SUSPENSION
Suspensi Depan
Shock absorber pegas hidrolik terbalik
Suspensi Depan
Shock absorber pegas hidrolik terbalik
FRONT TYRE
Ban Depan
Michelin 120/70-12
Ban Depan
Michelin 120/70-12
FRONT BRAKE
Rem Depan
Cakram hidrolik 240mm ABS, Kaliper Brembo
Rem Depan
Cakram hidrolik 240mm ABS, Kaliper Brembo
WET WEIGHT NO FUEL
Berat Basah Tanpa BBM
142 kg
Berat Basah Tanpa BBM
142 kg
WHEELBASE
Jarak Sumbu Roda
1.405 mm
Jarak Sumbu Roda
1.405 mm
DISPLACEMENT
Kapasitas
189 cc
Kapasitas
189 cc
COMPRESSION RATIO
Rasio Kompresi
12.1 : 1
Rasio Kompresi
12.1 : 1
MAXIMUM TORQUE
Torsi Maksimal
15.5 Nm @ 6500 rpm
Torsi Maksimal
15.5 Nm @ 6500 rpm
FINAL DRIVE
Penggerak Akhir
CVT V-belt
Penggerak Akhir
CVT V-belt
FRAME
Rangka
Rangka Trellis baja tubular
Rangka
Rangka Trellis baja tubular
REAR SUSPENSION
Suspensi Belakang
Mono Shock Absorber
Suspensi Belakang
Mono Shock Absorber
REAR TYRE
Ban Belakang
Michelin 140/60-13 M/C
Ban Belakang
Michelin 140/60-13 M/C
REAR BRAKE
Rem Belakang
Cakram hidrolik 175 mm ABS, Kaliper Brembo
Rem Belakang
Cakram hidrolik 175 mm ABS, Kaliper Brembo
HEIGHT
Tinggi
155 mm
Tinggi
155 mm
FUEL TANK CAPACITY
Kapasitas Tangki BBM
9 l
Kapasitas Tangki BBM
9 l
